A-Track 3-Phase Power supply

The A-Track 3-Phase Power Supply connects your 3-phase track system directly to the mains (230V). This component acts as the entry point for the track, ensuring that all three phases (L1, L2, L3) are available across the entire length for your track spotlights.

What is the difference between Left and Right?

Since a 3-phase track is asymmetrical (featuring a specific earth ridge on one side), choosing the correct power supply is essential. The difference between the Left and Right variants is determined by the side where the earth conductor runs within the track:

• Left Power Supply: Used when the power feed is at the end of the track where the earth conductor is on the left side (viewed from the starting point).
• Right Power Supply: Used when the power feed is at the end where the earth conductor is on the right side.

By selecting the correct variant, the power supply aligns perfectly with the internal copper conductors of the track without interrupting polarity. This ensures a safe installation and a clean visual finish, with the power supply sitting directly in line with the track profile.

• Universal 3-Phase Feed: Compatible with all A-Track 3-phase track systems.
• Left or Right Options: Ensures a technically correct connection based on the track's earthing side.
• Safe 230V Connection: Robust internal connection for reliable power delivery to all three phases.
• Easy Installation: Direct mounting at the end of the track with a secure mechanical lock.
• Sleek Design: Available in black and white for a seamless transition between the power supply and the track profile.
